The latest generation of vehicles offers increasingly higher safety standards and an enhanced driving experience. At the core of these achievements lies a trio of cutting-edge technologies: radar, LiDAR and cameras. Each of these sensors brings unique capabilities to the table, and their synergistic interplay propels automotive safety and comfort to new heights.
The real power of these technologies is in their ability to work together seamlessly. Radar provides long-range detection and speed information, while LiDAR offers precise object location and classification. Cameras interpret the visual scene, adding context to the data collected by the other sensors.
By combining these capabilities, vehicles can achieve situational awareness that surpasses human capabilities. As technology continues to evolve, we can expect even more sophisticated sensor systems to emerge. This article presents some of the latest trends driving the evolution of these sensors and their integration into the vehicle to implement increasingly advanced capabilities.
Trends in radar technology
Automotive radar technology is essential for implementing advanced driver-assistance systems (ADAS). Modern vehicles are equipped with radar sensors that facilitate several advanced functionalities, such as automatic emergency braking systems, front-collision warning, blind-spot recognition, lane-change assist, rear-collision warning systems, adaptive cruise control and stop-and-go.
The shift to 77 GHz
Since 24-GHz ultra-wideband (UWB) was phased out in 2022 in Europe and the U.S., automotive radar is now operating in these markets at 77–81 GHz, reserved for high-precision and short-range detection. This wider bandwidth significantly improves range resolution and accuracy, allowing sensors to separate two closely spaced objects. For instance, a 77-GHz radar has a range resolution of 4 cm, while a 24-GHz radar achieves a range resolution of only 75 cm. This disparity in resolution enables enhanced detection capabilities for many objects nearby.
4D radar
4D radar offers enhanced precision and comprehensive data regarding objects in 3D space, encompassing their vertical position (also known as elevation), in addition to the distance, horizontal locations and velocity that this radar already provides. The capacity to accurately determine the vertical displacement of objects using 4D and imaging radar is a crucial requirement for autonomous vehicles (AVs) to accurately interpret objects in the vertical domain.
NXP Semiconductors recently disclosed a partnership with Tier 1 supplier sinPro to create an entry-level 4D imaging radar solution that will start OEM production in the latter half of 2024. The solution uses NXP’s specialized chipset that incorporates the 16-nm FinFET S32R41 automotive imaging radar processor and the TEF82xx RFCMOS transceiver in a dual-cascading configuration.
Satellite architecture
The typical “edge” architecture envisions the integration of advanced radar sensors that transmit processed data over a CAN or Ethernet interface to an ADAS electronic control unit (ECU). This architectural design is undergoing a transformation toward satellite architectures.
In these designs, the sensor heads located around the vehicle transmit pre-processed data to a central ECU via a high-speed, 1-Gbit Ethernet interface. Satellite architecture facilitates the consolidation of data processing by using minimally processed data at the central processor, in contrast to the edge architecture, where individual radar sensors perform complete data processing autonomously.
Centralized processing facilitates the integration of efficient sensor fusion algorithms, leading to enhanced precision in decision-making processes. The integration of sensor inputs in conjunction with these algorithms enhances overall sensing performance and yields a rather accurate perception map.
For example, Texas Instruments Inc. (TI) has developed the AWR2544 FMCW 77-GHz millimeter-wave radar-on-chip sensor (Figure 1) for satellite radar architectures. The device incorporates a 77-GHz transceiver that is seamlessly integrated with four transmitters and four receivers, resulting in enhanced range-detection capabilities, higher-accuracy decision-making for ADAS and improved overall performance.
In addition, the satellite radar chip incorporates a radar processing accelerator that is tailored for cost-effectiveness, as well as a 1-Gbit/s Ethernet interface that enhances throughput for the generation and streaming of range fast Fourier transform compressed data. The device can implement Automotive Safety Integrity Level (ASIL) B and offers a safe execution environment through a hardware security module.
Figure 1: TI’s AWR2544 FMCW satellite radar-on-chip sensor improves sensor fusion, delivering more accurate decision-making for ADAS. (Source: Texas Instruments Inc.)
CPD systems
The child presence detection (CPD) feature detects children left behind inside the vehicle and triggers a warning within seconds. This system, based on UWB technology with sensing features, enables vehicle manufacturers to meet future safety targets of Euro NCAP and U.S. regulations for 2025.
Leveraging its CoSmA UWB Digital Access solution, Continental AG has developed a CPD system (Figure 2) that enables drivers to use their smartphone as a car key for hands-free access. To detect children who were left behind, the UWB system acts as a radar, receiving its own transmitted UWB signals back from the micro motions of an object.
By detecting a change in the frequency or phase of a returned signal, the distance and velocity of the moving target can be measured. Even the tiniest motion, such as the movement of a child’s chest while breathing, can be detected by the sensors. If the child is with an adult, the CPD system does not generate any alarm.
Figure 2: The Continental CPD solution uses respiration rates and micro-body movements to classify passengers as infants, children or adults and can send audible, visual or haptic alerts to the driver after 10 seconds at the latest if a child is left behind in the vehicle. (Source: Continental AG)
Trends in LiDAR
LiDAR uses laser pulses to create a 3D map of the surroundings, thus enabling accurate object detection, distance measurement and environment understanding. This information is critical for achieving higher levels of autonomous driving.
Today, the first Level 3 AVs are commercially available in all three major automotive markets: the U.S., China and Europe. Level 3 autonomous driving is classified as conditional driving automation, meaning drivers must be adequately prepared to assume control of the vehicle upon request. At Levels 4 and 5, drivers are permitted to be disengaged. Despite its higher cost, LiDAR is considered a more accurate sensing technology than radar sensors, providing high-resolution and 3D mapping under almost all weather conditions.
A key strategy for bringing the cost of LiDAR down to an acceptable level is product innovation. Manufacturers of LiDAR are currently focusing their research and development efforts on two areas: the transition from mechanical to solid-state LiDAR and the use of semiconductor chips to replace the conventional discrete design.
Perception software
Perception software combines advanced LiDAR sensors with state-of-the-art AI algorithms. The sensors operate as the eyes of the vehicle, facilitating the perception of the surroundings and acquiring data from the environment to produce a point cloud.
One example is MicroVision’s MAVIN N, a compact and customizable laser beam scanner that uses perception software to enable object detection, classification and tracking. The device, shown in Figure 3, integrates multiple solutions into a single, low-profile box.
Figure 3: MicroVision’s MAVIN N on a vehicle roof (Source: MicroVision)
MicroVision has optimized the perception software to process sensor measurements directly on the LiDAR sensors, thereby reducing power consumption, thanks to a highly efficient system-on-chip. Because the sensor-specific perception processing is already done on-chip, compared with using expensive external ECU hardware, it simplifies the system architecture and reduces costs.
Trends in cameras
ADAS solutions are increasingly reliant on cameras for features such as adaptive cruise control, automatic emergency braking, lane-keeping assistance and traffic-sign recognition. Combining cameras with other sensors such as radar and LiDAR enhances the precision and reliability of these systems.
The integration of cameras and LiDAR sensors in particular combines vision-based detection with depth perception for enhanced accuracy in object detection and localization, particularly critical for autonomous-driving applications.
Surround-view cameras
Cameras with 360° surround view are gaining popularity for their ability to provide a bird’s-eye perspective, aiding in parking and maneuvering. Surround-view cameras provide a complete visual image of the vehicle from above, warning drivers about pedestrians, vehicles or obstacles that may be in the vehicle’s path but not within their immediate line of sight.
Multiple wide-angle cameras are strategically positioned around the vehicle, typically at the front, rear and under the side mirrors, to form a typical surround-view camera system. Each camera photographs a specific area around the vehicle, covering all directions. These images are combined using advanced software to produce a bird’s-eye view of the vehicle’s surroundings. This view is then displayed on the car’s infotainment screen.
Thermal imaging
When applied to the automotive industry, thermal imaging can be used to enhance the safety of road users. For example, Valeo and Teledyne FLIR LLC are collaborating to deliver the first ASIL B thermal imaging technology for night-vision ADAS.
This system (Figure 4) will use Valeo’s ADAS software stack to provide nighttime functionality for applications such as automatic emergency braking in autonomous, commercial and passenger vehicles. Valeo will integrate Teledyne FLIR’s thermal vision technology to provide comprehensive night vision.
Figure 4: The integration of FLIR thermal imaging will increase the safety of road users at night. (Source: Teledyne FLIR)
