Q-Tech Corp. has introduced the QTCC578 Series of ultra-miniature crystal oscillators, touting exceptional phase noise floor of -155 dBc/Hz for high-performance, low-voltage applications. These include telecom applications such as fiber channel, telecom, SONET, Ethernet/SynchE and microprocessor clock to military/aerospace applications such as navigation, avionics, and commercial off-the-shelf (COTS).
The QTCC578 oscillators are built using a miniature strip AT quartz crystal in a low-profile ceramic (5 x 7 x 1.5 mm) hermetically-sealed package with gold-plated contact pads. They provide supply voltages of 3.3 VDC and 2.5 VDC.
Recommended
Crystals and oscillators get smaller
These LVDS logic differential output crystal oscillators are available with frequency set to between 100.000 MHz and 250.000 MHz, with temperature range/frequency stability selectable from ±25 ppm at -40°C to 85°C to ±100ppm at -55°C to+125°C.
The QTCC578 oscillators are EAR99-classified. They are lead-free and RoHS compliant. Military screening per MIL-PRF-55310 is available.
Available now, lead times for the QTCC578 devices is about eight weeks without the optional MIL-PRF-55310 screening. Many standard frequencies are in stock. Pricing depends on the package, frequency, and screening level.
Q-Tech also recently introduced the QT723 and QT735 Series of space-qualified crystal oscillators, claiming the industry’s smallest surface-mount packages. The QT723 Series, measuring 2.5 x 3.2 mm, offers user-prescribed frequencies of 1.500 to 250 MHz, tri-state CMOS outputs powered by an input voltage of 1.8, 2.5 or 3.3 VDC. The QT735 Series, in a 3.2 x 5.0 mm package, is offered in CMOS, LVDS and LVPECL versions with input voltages up to 5.0 Vdc and selectable frequencies from 1.000 to 250 MHz. The new space, low-earth orbit oscillators are kRad(Si) total dose ionization radiation hardened, high shock (20,000 g) resistant, and screened per MIL-PRF-55310, Level B with PIND.
